Complete 2024 RAM Big Horn Stereo Wiring Diagram and Installation Guide

Start by locating the factory harness behind the dashboard cluster–commonly found near the climate control module. Identify the A-pillar connector (typically labeled C1 or C2) that carries amplified signals from the head unit to the door speakers. Use a digital multimeter to verify voltage on pins 1 (left front+) and 7 (right front+)–both should show 4-6V AC with music playing at moderate volume. If readings are absent or below 2V, check fuses 12 and 15 in the under-hood box (rated 25A) before proceeding.

Replace the OEM amplifier only if upgrading to component speakers with impedance below 3Ω. Disconnect the negative terminal first, then remove the kick panel to access the amplifier mounting bolts (torx T20). Tap into the red/black power wire (constant 12V) and orange/yellow accessory wire (switched 12V) for the aftermarket unit–use crimp connectors (not solder) for reliability. Route RCA cables away from spark plug wires to prevent engine noise; ground loops are eliminated by connecting the new amplifier’s grounding wire directly to the chassis using a stainless steel bolt.

For subwoofer installation, splice the blue/white remote turn-on wire from the receiver into the factory subwoofer harness (pin 8 on connector C3). Set the amplifier’s low-pass filter to 80Hz and phase to 0°–this matches the cabin tuning curve of early 2023 Laramie trims. Verify subwoofer cone movement with a 40Hz test tone before securing the enclosure; improper polarity will result in cancellation at higher volumes.

Use heat-shrink tubing on all exposed copper to prevent corrosion from road salt. Secure loose wires with zip ties every 12 inches, avoiding sharp edges on the firewall grommet. Test each channel with pink noise before final assembly–left rear speakers often fail first due to poor grounding at the tailgate hinge.

Electrical Connections for Premium Audio Systems in Latest Dodge Truck Variants

Locate the fuse box beneath the dashboard on the driver’s side–remove the panel by pulling the upper edge outward. Fuse #C2 (20A) supplies power to the radio’s memory, while #C1 (10A) feeds the ignition-controlled circuit. Use a multimeter set to 12V DC to verify continuity before splicing; incorrect connections risk damaging the OEM amplifier.

The front door speakers (6.5″ coaxial) connect via four wires: solid green (LF positive), green/black stripe (LF negative), solid violet (RF positive), and violet/black stripe (RF negative). Aftermarket units require an adapter harness (Metra 70-1002) to avoid cutting factory leads. Ground wires (black) terminate at the vehicle’s chassis near the kick panel–clean the contact surface with 120-grit sandpaper to prevent signal interference.

Subwoofer and Amplifier Integration

Factory-installed subwoofers use a separate 8-pin connector (pinouts: B+ orange, ground black/orange stripe, right rear positive gray/violet stripe, right rear negative gray/light blue stripe). Tap into the rear speaker outputs only if adding an external amp–bridging incorrectly overloads the stock Head Unit (Uconnect 5). For bass control, install a 300-watt capacitor between the amplifier’s power and ground to stabilize voltage during peak loads.

Steering wheel controls rely on a data bus interface; Metra ASWC-1 retains functionality when upgrading head units. Connect the pink/light blue wire (data) to the adapter’s input, then link the adapter’s output to the new radio’s SWC wire (typically purple). Resistors (680 Ω) may be needed for proper signal calibration–consult the vehicle’s service manual for exact values.

Verify all connections with a 5V test light before final assembly. Hidden splices (e.g., under seat or behind glove box) are prone to vibration failure–use solder and heat-shrink tubing for durability. The rear-view camera’s yellow/black wire (video) and green/red wire (reverse trigger) must route through the headliner to avoid pinching; secure with nylon ties every 6 inches.

Finding the Audio System Cable Assemblies in the Latest Dodge Pickup

Begin by removing the lower dash panel beneath the climate controls on the driver’s side. A single 7 mm bolt secures the panel; after loosening it, pull the panel downward to expose the wiring conduit. The main harness for the premium sound setup is bundled behind the fuse block, wrapped in black corrugated tubing.

Trace the primary harness upward toward the center console. Two connectors–one 16-pin and one 8-pin–attach to the amplifier mounted on the firewall. Disconnect the battery before handling these connectors to prevent short-circuiting the sensitive audio modules integrated into the system.

The rear door speaker harnesses run inside the sill plates. Pry the sill plate upward using a plastic trim tool, starting near the rear door hinge. Each door has a dedicated 4-pin connector tucked against the body pillar; note the color-coding–yellow for left, green for right–to avoid mismatching channels during upgrades.

Locate the subwoofer harness beneath the rear seat. Fold the seat forward and remove the two Torx T20 screws securing the access panel. The harness terminates in a 2-pin connector; ensure proper polarity when reconnecting–white with a stripe denotes positive.

Verifying Connections Before Modification

Check each harness run for factory-applied tie wraps securing cables to the chassis. Remove these carefully to avoid damaging insulation. The front tweeter harness is clipped into the A-pillar; detach the interior trim panel to access it without cutting into the headliner fabric.

Inspect the antenna lead near the glovebox. It is a coaxial cable bundled separately from the main harness, ending in a threaded F-connector. Rotate the connector counterclockwise to detach it from the receiver; apply dielectric grease when reattaching to maintain signal integrity.

Ensure all ground connections are corrosion-free. The amplifier ground strap bolts directly to the chassis behind the glove compartment using an M6 bolt. Clean the mounting surface with a wire brush before securing the ground to prevent audio distortion caused by poor conductivity.

Identifying Speaker Wire Colors and Their Functions for Aftermarket Upgrades

Start by matching factory wire colors to aftermarket harnesses using a multimeter. For Dodge trucks with premium audio systems, the front door speakers typically follow this scheme:

• Dark Green/Violet – Left front positive (+)
• Dark Green/Orange – Left front negative (-)
• Light Blue/Violet – Right front positive (+)
• Light Blue/Orange – Right front negative (-)

Rear speakers in crew cabs use:

• Brown/Violet – Left rear positive (+)
• Brown/Orange – Left rear negative (-)
• Tan/Violet – Right rear positive (+)
• Tan/Orange – Right rear negative (-)

Subwoofer outputs on Alpine or Harman Kardon factory systems are Gray (positive) and Gray/Black (negative). Always verify with a 1 kHz tone test–factory wires may deviate in base trims.

Common Deviations in Trim-Specific Wiring

Lower-tier models often consolidate grounds, leading to shared negative wires:

• Single Orange wire may serve as common ground for all speakers–split this first before connecting aftermarket amplifiers.
• Upscale trims with active noise cancellation add White and White/Black wires–these carry microphone signals, not audio. Disconnect or cap them to prevent feedback.
• If upgrading to a 5-channel amp, repurpose the Light Green/Violet (center channel) and Dark Blue/White (subwoofer pre-out) wires–these are RCA-level signals in premium setups.

For vehicles with factory navigation, the Yellow/Pink wire carries MUTE functionality–connect it to aftermarket units to retain steering wheel control integration.

Amplifier wiring requires isolating power and turn-on circuits:

1. Locate the Dark Blue/White wire at the back of the head unit–this is the remote turn-on lead.
2. Splice it into a relay triggered by the new deck’s remote wire to prevent parasitic drain.
3. For high-power setups, run 4 AWG power cable directly to the battery, fusing within 18 inches of the terminal–use ANL fuse holders (minimum 100A for 1000W systems).
4. Ground wires (Black) must connect to bare metal chassis points–avoid using existing factory grounds sized for small currents (

Test each channel before finalizing connections: a 50% volume sweep with pink noise reveals phase issues or weak outputs.

Step-by-Step Guide to Disconnecting the Factory Audio System for Replacement

First, gather the necessary tools: a trim removal kit, 8mm and 10mm sockets, a flathead screwdriver, and needle-nose pliers. Disconnect the negative terminal of the vehicle’s battery to prevent short circuits or electrical damage during removal. Work in a well-lit area to avoid misplacing fasteners or damaging interior panels.

Remove the dashboard trim surrounding the head unit by carefully prying it away with a plastic trim tool. Start at the edges, working inward to release clips without cracking the plastic. Some models have screws hidden behind air vent covers or the climate control panel–locate and remove these before proceeding. Store screws and small parts in a labeled container to avoid confusion during reassembly.

• Locate the mounting brackets securing the audio unit. Most factory systems use 4-6 bolts or screws–remove these with an 8mm or 10mm socket.
• Gently pull the unit outward until the wiring harness and antenna plug are visible. Press the release tabs on the harness connectors to detach them; do not yank or force the plugs.
• If the system includes an amplifier, check for additional wiring behind the unit or under the dashboard. Label each connector with masking tape to simplify installation of the new system.

Inspect the wiring harness for damage or corrosion before connecting the aftermarket system. If the factory harness is incompatible, use a wiring adapter specific to the vehicle model to ensure proper integration. Avoid cutting or splicing wires unless absolutely necessary, as this can lead to faulty connections or void warranties.

Reinstall remaining components in reverse order. Reconnect the battery terminal last to reset the vehicle’s electrical systems. Test all functions–including radio presets, Bluetooth, and climate controls–before securing the dashboard trim. If the new unit displays errors, recheck connections for loose plugs or incorrect wiring matches.
