Complete 2011 Kia Soul Radio Wiring Diagram Guide and Color Codes
Start by locating the main harness connector behind the stereo head unit–this is typically a 20-pin rectangular plug (part #98620-4X010) on the left side of the factory enclosure. Pin assignments follow this sequence: 1-4 (constant 12V, switched ignition, ground, antenna trigger), 5-8 (front left speaker +/-, front right speaker +/-), 9-12 (rear left speaker +/-, rear right speaker +/-), with the remaining pins reserved for amplifier activation, illumination control, and mute functions.
Use a multimeter set to 20V DC to verify voltage at pin 1 (should read battery voltage regardless of ignition state) and pin 2 (12V only when key is in ACC or ON). For speaker wires, test with a 1.5V AA battery–positive lead to the wire, negative to chassis ground; a faint pop confirms continuity and correct polarity. Mismatched colors in aftermarket kits often follow this mapping: white/black stripe → front left negative, gray/black stripe → front right negative, green/black stripe → rear left negative, violet/black stripe → rear right negative.
If upgrading to a touchscreen unit, splice the new harness between the OEM connector and ISO adapter, ensuring the CAN bus wires (pins 15 and 16, typically yellow and orange) remain uninterrupted–these control vehicle data like speed-sensitive volume and hands-free microphone. For vehicles with factory subwoofer output, check pins 17-18; if empty, the system lacks pre-amp outputs, requiring an external line converter with a 4-channel input and RCA output, tapped directly from the speaker wires.
Common complications include blown fuses (#F3 on the IP fuse block) from reverse polarity or shorted speaker wires. If the display flashes but no audio plays, inspect the amp remote wire (usually blue/white) for 12V; if absent, trace back to the head unit or ignition relay (IPDM E/R). Always disconnect the battery’s negative terminal before probing connections to prevent triggering the airbag fault codes.
Alternative schematics for premium audio systems (with amplifier) show an additional 12-pin connector below the glove box; pins 1-4 power the amp (constant/switched/ground/illumination), 5-12 handle the four speaker outputs with dedicated RCA-level signals. If retrofitting a non-factory amplifier, bypass this connector entirely and wire directly to the head unit’s speaker outputs, using a 200W inline fuse on the power feed to prevent fire hazards.
Vehicle Audio System Harness Guide for 2011 Compact Crossover
Locate the aftermarket harness adapter matched to the vehicle’s OEM connector: Metra 70-5602 or Axxess ASWC-1 for seamless integration. Verify pin assignments before installation–the factory speaker outputs (front/rear left/right) use 18-gauge wires, while power and illumination require 12-gauge. Ground the unit to the chassis at G201 behind the glovebox, securing with a 10mm bolt to prevent noise interference. Avoid splicing into ignition-switched power (red wire) directly; instead, tap the fuse box terminal 10 (IGN) with a mini add-a-circuit fuse to preserve battery life.
Connector Pinout Breakdown
| Pin | Color | Function | Notes |
|---|---|---|---|
| A1 | Yellow | Battery (constant +12V) | Connect fused (10A) directly to terminal |
| A4 | Red | Ignition (+12V switched) | Uses mini fuse tap (add 10A fuse) |
| A6 | Orange/White | Illumination dimmer | Adjusts brightness with dashboard lights |
| A7 | Green/Black | Left rear speaker (−) | Polarity critical; verify with multimeter |
| A12 | Brown/Yellow | Antenna trigger | Requires 12V to activate powered antenna |
Test all connections with a digital multimeter set to 20V DC. Probe the harness side before finalizing the stereo installation–ensure no voltage drops exceed 0.2V across ground paths. For talkback microphones in navigation units, route the pink/white wire (B10) along the A-pillar, avoiding the HVAC ductwork to minimize interference.
Finding the Audio System Connector in Your Compact Crossover
Start by removing the trim panel around the central console. Use a flathead screwdriver wrapped in electrical tape to pry off the clips without damaging the plastic. The lower dash cover typically snaps into place with six retaining clips–three on each side. Work methodically from left to right to avoid breaking the tabs.
The 10-pin harness sits directly behind the climate controls, secured by a single Phillips screw. Trace the bundled cables downward after loosening the fastener; the connector will be adjacent to the hazard light switch. If the bundle splits into two distinct plugs–one larger (16-pin) and one smaller (8-pin)–you’ve located the audio interface. Label each plug with masking tape before disconnecting.
For vehicles equipped with steering-wheel controls, an additional 4-pin mini-plug hides behind the glove compartment release lever. Slide the panel forward to access it–it’s held by friction-fit guides, not screws. Some models include a separate antenna lead; it’s thinner, shielded, and terminates near the passenger-side firewall within the same cavity.
Ground wires are typically black with yellow stripes and attach to a bolt behind the ashtray cavity. Verify continuity with a multimeter before reassembly–resistance should read below 0.5 ohms. If corrosion is present, clean the contact point with a wire brush and apply dielectric grease.
Factory amplifiers mount under the driver’s seat. To reach them, tilt the front seats fully backward and remove the carpeted tray. Three T10 torx screws secure the metal bracket; disconnect the 18-gauge power lead before removing the unit. Replace the amplifier only if speaker distortion persists after verifying all connections upstream.
Matching Harness Colors to Head Unit Connections for Custom Setups
Locate the 12V constant power lead–typically a yellow wire–before connecting anything. This strand must link directly to the battery via an inline fuse rated no higher than 15 amperes, positioned within 18 inches of the terminal. Skip this step and risk incomplete memory retention across device resets or parasitic battery drain.
Trace the red ignition-switched cable next. Verify its function by toggling the key: meter readings should spike to 12-14V when the engine cranks, dropping to zero once the key retracts. Pair this with the yellow strand using a butt connector to maintain accessory relay activation; using solder alone weakens under vibration, inviting intermittent faults.
- Ground connection–usually black–requires an unpainted chassis point near the mounting bracket. Avoid stacking it with speaker negatives; corrosion spreads faster than expected.
- Antennas activate via a blue/white remote lead. Connect it last to prevent shorting the amplifier turn-on circuit.
- Factory steering wheel controls often route through a pink or purple wire; tap into it with a 680-ohm resistor to prevent error codes.
Speaker polarity follows a simple rule: lighter-colored strands (gray, green, purple) carry positive signals, while darker mates (gray/black, green/white, purple/black) denote negatives. Break the harness at the firewall connector–never splice mid-wire–to preserve OEM harness integrity during future troubleshooting. Double-check clips for correct seating; a misaligned fit dims left rear output by 30% due to impedance mismatch.
For parking sensor integration, locate the orange illumination strand and tie it into the dash dimmer circuit. Test aftermarket components at half-brightness prior to final assembly; LEDs draw 60mA per unit, exceeding 1A combined can trip the fuse box thermal cutout.
Step-by-Step Guide to Removing the Factory Audio System
Disconnect the vehicle’s battery first to prevent electrical shorts. Locate the negative terminal–usually marked with a minus symbol–and use a 10mm wrench to loosen the clamp. Set the cable aside where it cannot reconnect accidentally. This prevents airbag triggers or system resets during removal.
Detach Interior Trim Panels
Use a plastic pry tool to gently lift the perimeter trim around the center console. Begin at the bottom edge near the gear shift, applying even pressure to avoid snapping clips. Work upward, releasing hidden fasteners behind the climate controls and cup holders. For models with a lower dashboard extension, remove the screw concealed beneath the ashtray or storage bin before pulling the panel free.
Slide the audio head unit outward once trim is removed. Press the metal release tabs on each side–typically four in total–and pull the unit straight out using firm, steady force. If resistance is felt, check for overlooked screws (often Torx T20) securing the frame. Disconnect the harness and antenna cable by pressing the release tabs before lifting the unit completely away. Label each connector for reassembly to avoid confusion later.
Ensuring Peak Audio System Integration
Match power delivery cables directly to the vehicle’s fuse box using a 10-15 amp fuse for the primary feed. Locate an ignition-switched slot–confirmed via multimeter at 12V during accessory or RUN mode–to prevent battery drain. Avoid splicing into existing circuits handling high loads like headlights or wipers; interference may distort signal clarity. Use 16-gauge wire for short runs (under 6 feet) and 14-gauge for longer connections to maintain voltage stability.
Secure grounding at a bare metal chassis point near the stereo unit, sanded free of paint or corrosion. A poor ground introduces hum and weakens output–test continuity with a probe to ensure resistance below 0.5 ohms. If the factory bolt is unavailable, drill a new hole, deburr edges, and secure with a star washer for maximum contact. Never daisy-chain grounds or share them with other components; this invites noise into the signal path.
Speaker connections demand polarity precision: red terminal (+) to colored wire, black (-) to stripped or black wire. Reversing polarity causes phase cancellation, turning crisp highs into muffled, directionless audio. For aftermarket systems, use oxygen-free copper cables (minimum 18-gauge for door speakers, 16-gauge for subwoofers) to reduce resistance. Twist pairs together for each channel to minimize electromagnetic interference, especially near the engine bay or power cables.
Isolate signal wires from power wires by routing them on opposite sides of the dashboard or through separate conduit. Crossings should occur at 90-degree angles to prevent induced noise. For amplified setups, add a noise filter capacitor (4700µF) between the power input and ground; this stabilizes voltage drops during bass-heavy passages, eliminating dimming lights or clipped distortion.
Terminate all splices with solder and heat-shrink tubing–crimp connectors alone degrade over time. For plug-and-play adapters, verify pinouts via a wiring schematic before connection; misaligned pins can fry the head unit or onboard modules. Test each stage (power, ground, speakers) with a 12V test light before final assembly: a lit bulb confirms integrity, while flickering indicates a weak connection needing rework.
